Application: Fall arrest
Work positioning
Rope access (and rescue)
Attachment: Dorsal position (fall arrest), frontal chest (partial fall arrest)
Frontal waist (rope access and rescue)
On waist belt (work positioning)
Features: X-padding on shoulders, padded waist and legs
Gear loops on waist belt
Adjustment: Leg straps and waist belt (quick release buckles)
Carabiner connector in front (easy fitment)
Shoulder straps (standard buckles)
Sizing: Small, Medium, Large, XLarge and 2XLarge
Options: Harness step can be fitted (not supplied standard)
SANS 50361:2003 Full body harness; conforms to SANS 50358:2008 Work positioning; SANS 50362:2008 Connectors
Component: Material properties
Primary Webbing: Polyester 44mm wide with breaking strength of 22kN
Steel dee ring: Breaking strength of 3 ton
Standard buckle: Alloy steel 2/3 bar buckle so suit 44mm webbing
Plastic insert: Polypropylene molded insert
Carabiner: Steel screwgate carabiner with breaking strength of 22kN
Yarn: Polyester thread with colour contrasting to webbing colour
Label: Textile material 40mm wide with thermal transfer
Padding: High density foam padding 6mm
Quick release buckle: Alloy steel bayonet type buckle
Gear loop: Webbing loop 25mm with tubular PVC sleeve
Product standards: SANS 50361:2003 Full body harness
Conforms to: SANS 50358:2008 Work positioning, SANS 50362:2008 Connectors
Permit numbers: 10853/17054, 10853/17064, 10853/17055
Disclaimer and product limitations:
Maximum weight of user (including clothing, PPE and tooling) is 100kg up to Fall Factor 1, and 120kg up to Fall Factor 2.
Adequate training on correct use of this equipment must be provided to user by a competent person before this equipment is issued for use. Simply reading the equipment user instructions does not suffice as adequate training. This equipment must not be used by a person with any medical condition that could affect their safety when using the equipment in normal or emergency use. It is recommended that at least every three months the fall arrest system (or component) or other equipment be inspected by a competent person. The equipment is intended to be used for 'fall arrest', 'work restraint' and/or 'rope access' as indicated. This equipment is not intended to be used for any other purpose other than indicated and may not be used outside of its limitations. This equipment becomes obsolete 5 years from manufacture date, regardless of the condition of the equipment. This equipment must be used strictly in accordance with the instructions given and without deviation. This equipment is used entirely outside of the manufacturers or suppliers control and accordingly the manufacturer or supplier cannot be held liable for any loss, claim or liability arising from any failure of this equipment from any cause whatsoever.
